SKU: BROBF16254
Brio Bi-Folding Door Track System For 16KG Top Guided Interior Panels - Available in Various Sizes
RRP: $242.36
Payments accepted:
Couldn't load pickup availability
Brio Bi-Folding Door Track System
PLEASE NOTE: Track system only (we don't sell doors)
PLEASE NOTE: This item is Non-returnable. Upon placing your order, it CAN'T be cancelled or returned (unless faulty or damaged)
This is a non-stocked item which leaves the warehouse in 10 business days after payment is made.
Door Track System is incredibly popular because they are stylish and efficient as space-saving doors for separating rooms or partitioning huge work spaces in homes and offices.
Door Track System Function - doors have rollers attached at the top, you lift them up and place them in the track. The guide on the floor then keeps the door in line as you slide it from one side to the other. Both doors are offset and slide, so one is in front of the other.
Features:
- Suitable for residential wardrobes and folding cupboards
- Ideal for use on openings with non-rebated jambs as only simple framing at the head is required to take the top track
- The pivot arrangement allows the panels to fold open to about 100 degrees, allowing unhindered access to over 90% of the opening
- Bottom guide channel not necessary
Specifications:
-
Max Panel Height:
- 2400mm (for panels 29-35mm thick)
- 2040mm (for panels 23-35mm thick)
- Max Panel Weight: 16kg
- Max Panel Width: 620mm
- Min Panel Thickness: 23mm
-
Available Sizes:
- 915mm
- 1250mm
- 1830mm
- 2500mm
Brio Bi-Folding Door Track System
BF16-25/4
PLEASE NOTE: Track system only (we don't sell doors)
PLEASE NOTE: This item is Non-returnable. Upon placing your order, it CAN'T be cancelled or returned (unless faulty or damaged)
This is a non-stocked item which leaves the warehouse in 10 business days after payment is made.
Door Track System is incredibly popular because they are stylish and efficient as space-saving doors for separating rooms or partitioning huge work spaces in homes and offices.
Door Track System Function - doors have rollers attached at the top, you lift them up and place them in the track. The guide on the floor then keeps the door in line as you slide it from one side to the other. Both doors are offset and slide, so one is in front of the other.
Features:
- Suitable for residential wardrobes and folding cupboards
- Ideal for use on openings with non-rebated jambs as only simple framing at the head is required to take the top track
- The pivot arrangement allows the panels to fold open to about 100 degrees, allowing unhindered access to over 90% of the opening
- Bottom guide channel not necessary
Specifications:
- Max Panel Height:
- 2400mm (for panels 29-35mm thick)
- 2040mm (for panels 23-35mm thick)
- Max Panel Weight: 16kg
- Max Panel Width: 620mm
- Min Panel Thickness: 23mm
- Opening Width: 1831mm to 2500mm for two panels pivoted from each side
