Briton Panic Bar Commercial Grade Fire Rated Silver for Timber & Metal Double Doors B377E/SE

Briton Panic Bar
B377E/SE

Panic Bar allows for both doors to be locked closed and permits emergency exit from both doors (e.g. where emergency or panic situation could occur).

Panic Bar Function - a safety device for critical emergency. These are designed specially for doors that may be used in the event of an emergency that would require a fast and unencumbered escape, such as a fire evacuation.

Note: Panic bolt only, door not included

• Top and bottom latching and reversible to suit double door applications
• Can be used on aluminium, hollow metal or wood swinging commercial doors
• Features an anti-thrust device to prevent the bottom socket from being levered from the outside.

Features:

• Consists of 376E, 378E and 378DDS strike plate
• Dogging option is available for both 376 and 378 devices (Dogging not suitable for fire doors)
• Sizable to accommodate a range of door openings
• Non handed - will suit both left and right hand doors
• Handed but can be rehanded on site

Specifications:

• Door Type: Timber or Metal
• Stile Width:
  • 78mm minimum with 13mm rebates
  • 90mm minimum with 25mm rebates
• Door Width: 665mm to 1300mm per leaf
• Door Height: 2500mm standard. Extra long top shoot available for door heights up to 3350mm
• Material:
  • Zinc diecast chassis
  • Steel rods and crossbars
• Supplied as: Trade pack with all fixing hardware
• Finish: Silver Enamel
• Warranty: 5 Years
