Carbine CDC-5 Radius
CDC-5SA-MB
Door Closer is a mechanical device that closes a door in a controlled manner, preventing it from slamming.
Door Closer Function - A hydraulic device that is used to automatically close a door after it has been opened. Door closers are commonly used as a fire prevention measure, typically installed on fire doors, as well as helping to prevent draughts.
Features:
- Carbine Radius Rack & Pinion series includes four models with adjustable closing, latching speeds, and back check. They are all single-action closers with a transom mount on the push side and non-handed installation making them easy to install on inward or outward opening doors
- Supplied with everything you need for your next installation including standard and parallel arm fittings, and timber and self-drilling metal screws
- Fire rated for 2 hours
- Cycle tested to 500,000 cycles
- Adjustable closing & latching speed
- Adjustable back check 70 to 90 degrees
- Thermo-constant valve
- Surface mount
- Transom mount on push side
- Positional mounting for closer strength
- Supplied with standard and parallel arm fittings
- Single-action door
- Non-handed installation
- Supplied with timber and self-drilling metal screws
- Constructed with extruded anodized aluminium body
- Slide rail arms for the CDC range include the hold open insert
Specifications:
- Power: EN 2 to 6 (adjustable)
- Standard Arm: 180 Degree Opening
- Parallel Arm: 130 Degree opening
- Sliding Arm Pull: 180 degree, push 110 degree opening (120 degree CDC-5)
- Hold Open: 130 degree opening (180 degree, hold open angle 70 to 150 degree CDC-5)
- Material: Constructed from 6061 grade aluminum
- Suitable For Doors Weighing: 40kg to 100kg
- Body Length: 256.5mm
- Height: 60mm
- Width: 48mm
- Finish: Matt Black
Ratings:
- Tested to EN1154 standards
