SKU: BELVFJSSTONE70GSNSS
FritsJurgens New System One 70mm Pivot Point Non-Adjustable Narrow Floor Plate Satin Stainless Steel FJS/STONE70GSNSS
RRP: $1,622.50
Payments accepted:
Couldn't load pickup availability
There was an error loading products. Please try again.
Payments accepted:
Couldn't load pickup availability
FritsJurgens New System One
FJS/STONE70GSNSS
Pivot Sets are commonly used for large and heavy doors that could pose challenges for traditional hinge systems. These doors might include oversized commercial doors, industrial doors, and entrance doors in public buildings.
Pivot Set Function - used to facilitate the rotation or pivoting of doors around a vertical axis. Pivot sets are designed to enable doors to swing smoothly and efficiently while providing stability and support. They are often used in situations where traditional hinges may not be suitable due to the size, weight, or design of the door.
Features:
- System One is FritsJurgens most compact and narrow pivot hinge – a single pivot point, offering a free-swing pivot door for doors with slim door frames.
- The most ideal pivot hinge for narrow profile doors. With a height of just 18 mm this pivot hinge can be applied in a broad range of pivot door designs and applications
- Supplied with Fixings
Specifications:
- Material: Stainless Steel 420 Surgical Grade - Anodised Aluminium
- Maximum Door Weight: 500kg
- Door Rotation Revolving door: 360 degrees
- Double-acting: 180 degrees
- Single-acting: 90 degrees
- Door Height: Unlimited
- Door Width: 400mm to Unlimited
- Door Thickness: 50mm Minimum
- Pivot Point: 70mm Minimum
- Finish: Satin Stainless Steel
