McGrath Locks Grange Entrance Pull Handle Smart Lock - Available in Various Finishes

McGrath Locks Grange Entrance Pull Handle Smart Lock

Smart Lock is designed to perform locking and unlocking operations on a door when it receives such instructions from an authorized device using a wireless protocol and a cryptographic key to execute the authorization process.

Smart Lock Function - allows you to open your door without a physical key. Can be controlled remotely using a smartphone app.

Features:

• 5-in-1 smart entrance pull handle with multiple access methods
• Unlock via fingerprint, PIN code, RFID credential, Bluetooth smartphone, or mechanical key
• Bluetooth connectivity with the McGrath Locks App for easy lock and user management
• Optional Wi-Fi gateway support for remote locking and unlocking from anywhere
• Store and manage fingerprints, PIN codes, RFID credentials, and eKeys
• View audit trail to monitor who accessed the door and when
• Passage Mode keeps the door unlocked when required
• Anti-peep PIN function protects your access code from shoulder surfing
• Incorrect attempt lockout enhances security against unauthorized access
• Internal privacy button restricts entry to administrators and mechanical key override only
• Reset button can be disabled via the app for added security
• Includes door sensor for optional door position monitoring and automatic locking
• Supplied with a roller bolt accessory for consistent door closing
• Mechanical key override for emergency access
• USB-C emergency power input allows temporary operation using a power bank
• Low battery alerts via the lock and mobile app
• Durable tempered glass touchscreen
• Modern Australian-designed pull handle style ideal for contemporary homes
• Compatible with optional dummy pull handles for French and double-door installations

Specifications:

• Model: Grange Entrance Pull Handle Smart Lock
• Access Methods: Fingerprint, PIN Code, RFID Credential, Bluetooth (BLE), Mechanical Key
• Mobile App: McGrath Locks App
• Remote Access: Supported with optional McGrath Gateway
• Connectivity: Bluetooth Low Energy (BLE)
• Power Supply: 4 × AA batteries (not included)
• Emergency Power: USB-C power bank connection
• Door Thickness: 35-55 mm (extendable up to 100 mm with optional tailbar)
• Lock Type: Adjustable 60-70mm anti-saw SS304 bolt with roller bolt
• Outside Handle Dimensions: 900 × 60 × 30mm
• Inside Handle Dimensions: 901.8 × 60 × 30mm (85mm including turn knob)
• Outside Handle Projection: 67mm
• Screen: Tempered glass touchscreen
• Material: 304 Stainless Steel anti-saw bolt
• Australian Registered Design: No. 2021101919
• IP Rating: IP65 (external housing)
• Cycle Tested: 200,000 operations
• Designed For: Contemporary residential entrance doors.
• AvailableFinish:
  • Matt Black
  • Satin Stainless Steel
