Raven RP113 Timber Door Frame Perimeter Seal Door Stop Tasmanian Oak - Available in Various Sizes

Raven RP113 Timber Door Frame Perimeter Seal Door Stop

Door Stop Frame Seal are used to seal gaps at door perimeters. By sealing the gaps along the door frame you can significanly cut down on the infiltration of sound, light, drafts, moisture, fire and smoke.

Door Stop Frame Seal Function - to ensure a fire escape route free from smoke and the intumescent seals the gap between the door and frame to inhibit the spread of fire.

Features:

• A timber door stop frame seal suitable for plain or rebated frames.
• Can be used in conjunction with Raven door bottom seals and meeting stile seals (astragals).
• Available in genuine plantation Tasmanian oak
• Fixing nails supplied

Specification:

• Min/Max Gap: 0mm to 7mm
• Compression: 1mm to 3mm
• Fixing: Nailed (Nail fix. Zinc plated nails supplied)
• Door/Frame Construction: Timber
• Seal: Silicon Rubber Gasket
• Door Type: Single Inward Opening, Single Outward Opening, Double Inward Opening, Double Outward Opening
• Window Type: Awning (Outward Opening), Casement (Side Hung), Hopper (Inward Opening)
• Location: Head and jambs of single and double butt hinged doors.
• Finish: Tasmanian Oak
• Size:
  • Single Door Set (1 x 1000mm & 2 x 2100mm)
  • Double Door Set (3 x 2100mm)

Approval/s:

• Acoustic AUS/NZ: NCC F7D6
• Acoustic UK/EU: Approved Document E, Rated to BS EN ISO 717-1
• Smoke AUS/NZ: NCC S12C4, NZBC C/AS2 4.16.2(b)
• Smoke UK/EU: Approved Document B
• Energy AUS/NZ: NCC J5D5, ABCB Housing Provisions Standard 2022 13.4.4
