Lockwood Door Closer Non Hold Open
2024SIL

The Lockwood range of economy door closers is particularly quick and easy to install on most applications, ideally suitable where cost is a high priority. Multi position mounting template enables adjustment on site to meet most conditions also low stock holding as one model will cover 3 power sizes. Suitable for doors up to 1100 mm in width.

Features:

• Non handed. Suitable for left or right hand doors.
• Independent valves control closing and latching speeds which can be readily adjusted on site when required.
• Backcheck and hold-open models also available in this series, please see our store.

Specifications:

• Mechanism: Rack and pinion design.
• Materials: High purity die cast aluminium housing with hardened steel rack and pinion mechanism.
• Finish: Silver baked enamel.
• Power Selection Charts: The power of the door closer is altered by adjusting the position of the door closer body on the mounting template.
• Functions in Detail: All products include parallel arm bracket; Multi strength mounting (one model covers size 2, 3, and 4); Parallel Arm Size 2 and 3.
