Lockwood Standard Floor Spring Hold Open

PLEASE NOTE: This item is Non-returnable. Upon placing your order, it CAN'T be cancelled or returned (unless faulty or damaged)

This is a non-stocked item which leaves the warehouse in 10 business days after payment is made.

Floor Spring Door Closer is a mechanical door closing device mostly used for glass doors along with patch fitting. Mostly used where both pull and push movement is required. Floor springs are used is in Interior doors of a Business park, Malls, Hospital building.

Floor Spring Door Closer Function - designed to hold the door open when the door is opened past 90 degrees. Simple pushing of the door towards the closed position, activates the closer and it also commences the closing action of the door.

  • Designed to provide door control on manually operated double action doors in a wide range of commercial applications.
  • The mounting kit provided with the Lockwood 8800 Series will suit glass, timber and aluminium frame door construction as standard.


  • Hold-open 90 degree
  • Adjustable pivot inserts
  • Pivot door sets
  • Lockwood guaranteed
  • Suitable for timber, aluminium & glass doors


  • Max Door Weight: 120kgs
  • Max Door Width: 1100mm
  • Closing Torque: 39nm
  • Spring Size: Size 4 Standard Floor Spring 90 degree Hold-Open
  • Door Thickness: 32mm
  • Finish: Satin Stainless Steel
Barcode # 9311847868151
Brand Lockwood
